InterfaceSupport FormatNetwork
General Environment
Model |
Name |
DG03-A1D24 |
Mainboard |
OS | Android 11.0 |
| CPU | Cortex-A53 | |
| Chipset | RK3566 | |
| RAM | 2GB | |
| ROM | 16GB | |
Display |
Size | 23.8-inch |
| Backlight | E-LED | |
| Aspect Ratio | 16:9 | |
| Response Time | 8 ms | |
| Frequency | 60Hz | |
| Resolution | 1920 × 1080 | |
| Display Colors | 16.7 M | |
| Contrast | 1000:1 | |
| View Angle | 178°(H)/178° (V) | |
| Brightness | 500cd/m² (typ) | |
| Color Gamut | 72% | |
| Life | >30000 hours | |
Interface |
RJ45 | 1 |
| HDMI IN | 1 | |
| SD Card | 1 | |
| USB | 2 | |
| Earphone | 1 | |
Support Format |
Video | AVI (H.264,DIVX,DIVX,XVID)/rm/rmvb/MKV (H.264,DIVX,DIVX,XVID)/WMV/MOV/MP4 (.H.264,MPEG,DIVX,VID)/DAT (VCD )/VOB (DVD )/MP/MPEG/.MPG/FLV (H.263,H.264)/ASF/TS/TP/3GP/MPG |
| Audio | MP3/WMA/MP2/OGG/AAC/M4A/MA4/FLAC/APE/3GP/WAV | |
| Image | JPG/BMP/PNG/GIF | |
Network |
Wi-Fi | 2.4G |
| LAN | RJ45 | |
Speaker |
Power | 3W×2 |
Power |
Power Input | AC 100~240V 50/60Hz |
| Rated Power | 36W | |
| Standby Consumption | <0.5W | |
General Environment |
Operating Temperature | 0℃ to 50℃ |
| Storage Temperature | 20℃ to 60 | |
| Operating Humidity | 20% to 80% RH | |
| Storage Humidity | 10% to 90% RH | |
Physical Parameters |
Product Dimensions | 540 × 310 × 34mm(L×H×W) |
| Package Dimensions | 640 × 425 × 60mm(L×H×W) | |
| Net Weight | 3.5kg | |
| Gross Weight | 5.0kg |
