Model |
Name |
DG03-A3W32 |
DG03-A3W43 |
DG03-A3W49 |
DG03-A3W55 |
Mainboard |
OS | Android 11.0 | |||
| CPU | Quad Core Cortex-A53 | ||||
| RAM | 2GB | ||||
| ROM | 16GB | ||||
| Chipset | RK3566S | ||||
ID & MD |
ID | Simple style, black matte narrow frame | |||
| Texture of material | Support ul94-hb75 fire rating | ||||
| MD | SupportVESA hanger (horizontal and vertical) | ||||
Model |
Size | 32-inch | 43-inch | 49-inch | 55-inch |
| Backlight | E-LED | ||||
| Resolution | 1920 × 1080 | ||||
| Aspect Ratio | 16:9 | ||||
| Contrast | 1600:1 | ||||
| ResponseTime | 8 ms | ||||
| Frequency | 60Hz | ||||
| Visual Angle | |||||
| Brightness | 350cd/m² (typ) | ||||
| Color Gamut | 72% | ||||
| Life | >30000 hours | ||||
Interface |
RJ45 | 1 | |||
| USB | 2 | ||||
Network |
Wi-Fi | 2.4G | |||
| LAN | RJ45 | ||||
Speaker |
Power | 3W×2 | |||
Support Format |
Video | (H.264,DIVX,DIVX,XVID)/rm/rmvb/MKV (H.264,DIVX,DIVX,XVID)/WMV/MOV/MP4 (.H.264,MPEG,DIVX,VID)/DAT (VCD )/VOB (DVD)/MP/MPEG/.MPG/ FLV (H.263,H.264)/ASF /TS/TP/3GP/MPG |
|||
| Audio | MP3/WMA/MP2/OGG/AAC/M4A/MA4/FLAC/APE/3GP/WAV | ||||
| Image | JPG/BMP/PNG/GIF | ||||
Power |
Power Input | AC 100~240V @50/60Hz | |||
| Rated Power | 50W | 65W | 75W | 85W | |
| Standby Power | <5W | ||||
General Environment |
OperatingTemperature | 0℃ to 45 | |||
| StorageTemperature | 20℃ to 60 ℃ | ||||
| Operating Humidity | 20% to 80% | ||||
Mechanical |
Product Dimensions (L*H*W) | 720 × 416 × 51.1(mm) | 963 × 553 × 51.1(mm) | 1118 × 639 × 51.1(mm) | 1235 × 708 × 51.1(mm) |
| Package Dimensions (L*H*W) | 810 × 544 × 147(mm) | 1055 × 682 × 147(mm) | 1212 × 770 × 147(mm) | 1326 × 836 × 147(mm) | |
| NetWeight | 8 kg | 13 kg | 18 kg | 25 kg | |
| GrossWeight | 10 kg | 16.3 kg | 22 kg | 29.3 kg | |
