SenseFace 4 Series adopts the latest intelligent engineering facial authentication and in-glass fingerprint technology. It supports fingerprint, facial, card authentication with large capacity and speedy authentication, adopts ultimate antispoofing algorithm for facial authentication against almost all types of fake photos and videos attack, which offering secure biometric authentication. SenseFace 4 Series is an access control terminal featuring a video intercom function and supports ONVIF protocol. It fully improves the video intercom experience and can be compatible with video intercom indoor unit with SIP protocol (Version 2.0). Besides, SenseFace 4 Series supports multiple communication protocols. Its firmware has AC push and can convert to TA push and it is compatible with various AC or TA software. It can change to BEST protocol to link with ZKBio Zlink (AC module).
Features
· Visible Light Facial Authentication Technology, supports Mask Detection
· Anti-spoofing algorithm against almost all kinds of print attack (laser, color and B/W photos), videos attack and 3D mask attack
· Multiple Authentication Methods: Face / Card / Password (Virtual Keypad) / Palm (optional and coming soon)
· Available card modules: 125KHz ID Card (ID / HID Prox) / 13.56 MHz IC Card (IC / Felica) / 125KHz & 13.56MHz Dual Frequency Card (ID & IC & DESFire EV1 / EV2)
· Advanced access control functions (Wiegand input and output; RS485 communication; Electric Lock; Door Sensor; Exit Button)
· Capacity: 10,000 face templates; 10,000 cards; 200,000 logs; and 3,000 palm templates (coming soon)
· Attained IP66 Protection Rating With Dustproof and Waterproof
· Optional exclusive feature (coming soon): Facial authentication of multiple people at once (up to 4 people)
| Model | SpeedFace M4 |
| Order ID | AC01-SP30H-P25 |
| Display | 5"@ ISP Color LCD Screen (1280*720) |
| Camera | Binocular Camera @ 2MP WDR |
| Operation System | Linux |
| Hardware | CPU: Quad Core A53 @1.2GHz RAM: 1GB; ROM: 8GB Supplement Light: No Virtual Keypad: 16 Keys Casing Color: Metallic silver |
| Authentication Method | Face / Card / Password (Virtual Keypad) / Palm (optional and coming soon) |
| Face Template Capacity | 10,000 (1: N) |
| Palm Template Capacity | 3,000 (1: N, optional and coming soon) |
| RFID Card Capacity | 10,000 (1: N) |
| User Capacity | 10,000 (1: N) |
| Transaction Capacity | 200,000 (Optional : 500K) |
| Max. User Password Length | 8 Digits |
| Biometric Authentication Speed | less than 0.1 sec (Facial Authentication, Field Test Result) less than 0.14 sec (Palm Authentication, Field Test Result) |
| Touchless Biometric Operating Lighting Environment | 40cm to 140cm (Facial Authentication) 18cm to 40cm (Palm Authentication, optional and coming soon |
| False Acceptance Rate (FAR) % | ≤0.01% (Facial Authentication) =0.01% (Palm Authentication) |
| False Rejection Rate (FRR) % | ≤0.02% (Facial Authentication) =1.3% (Palm Authentication) |
| Biometric Algorithm | ZKFace V6.0 & AMTPalmvein V32 |
| Dimension | 103.83 * 212.41 * 50.60 (mm) (W*H*D) |
| Card Type | ID Card@125 kHz (Standard) IC Card@13.56 MHz (Optional) HID Prox@125 kHz (Optional) Felica Card@13.56 MHz (Optional) Optional Multi-Tech Module: Module1: ID & IC & DESFire EV1 / EV2; (125 kHz & 13.56 MHz Dual Frequency) |
| QR Code | Dynamic QR code on the ZKBio CVAccess mobile application (By Face Camera) |
| Communication | TCP / IP*1 Wi-Fi (IEEE802.1b / g / n / a) @ 2.4 GHz / 5 GHz (Optional, and coming soon) Wiegand (Input & Output)*1 RS485: ZKTeco RS485*1 Aux Inputs *1, Electric Lock*1, Door Sensor*1, Exit Button*1, Alarm*1, 12V Output*1 |
| Standard Functions | ADMS, Photo Capture, Event Photo Capture, Up to 14-digit User ID, Access Levels, Groups, Holidays, Anti-Passback, Record Query, Schedule Bell, Tamper Switch Alarm, Automatic Status Switch (Effective only under T&A rules), Multiple Verification Methods, T9 Keyboard (Input), AC Push and TA Push Protocol Switch, HTTPs / SSH Backend Access, Mask Detection, Dynamic QR Code (by camera) |
| Optional Functions | Webserver, Video Door Phone: SIP Client (Version2.0), ONVIF (Compatible with Profi le S, Profi le T, Profi le G, Profi le C, Profi le Q & Profi le A), Wi-Fi, POE, SRB, External Bell |
| Video Intercom | Video Intercom(ZKTeco Private Protocol via TCP / lP) Support Devices: Standalone Terminal: SpeedFace M4 (Only ZAM210 Platform) Indoor Monitor: VT07-B01, VT07-B01-W Video Intercom (Standard SIP Protocol) Support Devices: Standalone Terminal: SpeedFace M4 (Only ZAM210 Platform) Indoor Monitor: VT07-B22L, VT07-B26L-W Software: ZKBio CVAccess, BioTalk Pro Mobile App: ZKBio Zlink, ZKBio Zexus |
| Access Control Interface | RS485 (RS485 Card Reader / Biometric Reader) |
| Power Supply | DC 12V 3A (Optional) POE: IEEE 802.3at (Optional) |
| Operating Temperature |
-10°C to 50°C (14°F to 122°F) |
| Operating Humidity | 10% to 90% RH (Non-condensing) |
| Dimensions | 212.42mm*103.83mm*50.60mm (L*W*H) |
| Gross Weight | 1.32 Kg |
| Net Weight | 0.77 Kg |
| Supported Software | On-Premise Software: ZKBio CVAccess (AC PUSH) & ZKBio Time (TA PUSH) Cloud-based Software: ZKBio Zlink (Supports Web Portal & Mobile App) |
| Installation | Wall-mount (Compatible with Asian Gang-box / Single Gang-Box) |
| Ingress Protection Rating | IP66 (waterproof and dustproof ) |
| Certifications | ISO14001, ISO9001, CE, FCC |
