The SpeedFace-V4L Pro series uses intelligent engineering facial recognition algorithms and the latest computer vision technology, featuring a video intercom function.
What sets the SpeedFace-V4L Pro apart is its 4-inch color LCD touch screen, a 2MP binocular camera, a built-in microphone, and a speaker for two-way video communication. There are two ways to use video intercom functions. Firstly, users can have a video phone through the ZKBio Zlink or ZKBio Zexus app. Secondly, the terminal can connect the indoor station via SIP protocol.
The SpeedFace-V4L Pro series can also integrate with the ZKBio Zexus to support Dynamic QR codes for access control or time and attendance protocols. Furthermore, the SpeedFace-V4L Pro series incorporates the ultimate anti-spoofing algorithm for facial recognition, protecting most fake photos and video attacks.
| Model | SpeedFace-V4L Pro SpeedFace-V4L Pro-QR SpeedFace-V4L Pro-RFID |
| Display | 4"@ TFT Color Touch LED Screen (480*800) |
| Camera | Binocular Camera @ 2MP |
| Operation System | Linux |
| Hardware | CPU: Dual Core@1GHz RAM: 1GB; ROM: 8GB Speaker: 8 ohm@1 W Microphone: *1 (Sensitivity: -32dB / Omni-directional / Signal-to-Noise Ratio: 58dB / Impedance: 2.2kΩ) Fingerprint Sensor: In-Glass Fingerprint |
| Authentication Method | SpeedFace-V4L Pro: Face / Fingerprint / Card / Password (Virtual Keypad) SpeedFace-V4L Pro-QR: Face / Scramble QR Code / Card / Password (Virtual Keypad) SpeedFace-V4L Pro-RFID: Face / Card / Password (Virtual Keypad) |
| User Capacity | SpeedFace-V4L Pro: 6,000 (1:N) (Standard) / 10,000 (1:N) (Optional) SpeedFace-V4L Pro-QR: 6,000 (1:N) (Standard) / 10,000 (1:N) (Optional) SpeedFace-V4L Pro-RFID: 6,000 (1:N) (Standard) / 10,000 (1:N) (Optional) |
| Face Template Capacity | SpeedFace-V4L Pro: 6,000 (1:N) (Standard) SpeedFace-V4L Pro-QR: 6,000 (1:N) (Standard) SpeedFace-V4L Pro-RFID: 6,000 (1:N) (Standard) |
| Fingerprint Template Capacity | SpeedFace-V4L Pro: 6,000 (1:N) (Standard) SpeedFace-V4L Pro-QR: / SpeedFace-V4L Pro-RFID: / |
| Card Capacity | SpeedFace-V4L Pro: 6,000 (1:N) (Standard) / 10,000 (1:N) (Optional) SpeedFace-V4L Pro-QR: 6,000 (1:N) (Standard) / 10,000 (1:N) (Optional) SpeedFace-V4L Pro-RFID: 6,000 (1:N) (Standard) / 10,000 (1:N) (Optional) |
| Transaction Capacity | SpeedFace-V4L Pro: 200,000 (1:N) SpeedFace-V4L Pro-QR: 200,000 (1:N) SpeedFace-V4L Pro-RFID: 200,000 (1:N) |
| Max. User Password Length | 8 Digits |
| Biometric Verification Speed | less than 0.35 second (Facial Recognition) less than 0.5 second (Fingerprint Recognition) |
| Touchless Biometric Recognition Distance | 30 cm to 170 cm @Face |
| False Acceptance Rate (FAR) % | SpeedFace-V4L Pro: ≤0.01% (Facial Recognition); ≤0.0001% (Fingerprint) SpeedFace-V4L Pro-QR: ≤0.01% (Facial Recognition) SpeedFace-V4L Pro-RFID: ≤0.01% (Facial Recognition) |
| False Rejection Rate (FRR) % | SpeedFace-V4L Pro: ≤0.02% (Facial Recognition); 0.01% (Fingerprint) SpeedFace-V4L Pro-QR: ≤0.02% (Facial Recognition) SpeedFace-V4L Pro-RFID: ≤0.02% (Facial Recognition) |
| Biometric Algorithm | SpeedFace-V4L Pro: ZKFace V3.6 & ZKFinger V13.0 / V10.0 SpeedFace-V4L Pro-QR: ZKFace V3.6 SpeedFace-V4L Pro-RFID: ZKFace V3.6 |
| Card Type | ID Card@125 kHz (Standard) IC Card@13.56 MHz (Optional) Optional Multi-Tech Module: Module1: ID & IC & DESFire EV1 / EV2 & Felica; (125 kHz & 13.56 MHz Dual Frequency); Module 2: ID & IC & DESFire EV1/EV2 & FeliCa & HID Prox & HID iClass (125 kHz & 13.56 MHz Dual Frequency) |
| QR Code | SpeedFace-V4L Pro: / SpeedFace-V4L Pro-QR: Dynamic QR codes on the ZKBio Zexus SpeedFace-V4L Pro-RFID: / |
| Communication | TCP/IP*1 Wi-Fi (IEEE802.1a/b/g/n/ac) @ 2.4 GHz / 5G GHz Wiegand (Input & Output)*1 RS485: ZKTeco RS485*1 USB: Type A (USB Drive Only)*1 Aux Inputs *1, Electric Lock*1, Door Sensor*1, Exit Button*1, Alarm output*1, Wired Doorbell*1 |
| Standard Functions | ADMS, DST, 14-digit User ID, T9 Keyboard (Input), Photo Capture, Event Photo Capture, Record Query, Tamper Switch Alarm, Automatic Status Switch, Multiple Verification Methods, Anti-Passback, Wired Doorbell, Schedule Bell, HTTPs / SSH Backend Access, AC Push and TA Push Protocol Switch |
| Optional Functions | Wi-Fi, WorkCode, Video Intercom, Wireless Doorbell, DM10 |
| Video Intercom | Video Intercom (ZKTeco Private Protocol via TCP/lP) Support Devices: Standalone Terminal: SpeedFace-V4L Pro Series(Only ZAM230 Platform) Indoor Monitor: VT07-B01, VT07-B01-W Video Intercom (Standard SIP Protocol) Support Devices: Standalone Terminal: SpeedFace-V4L Pro Series(Only ZAM230 Platform) Indoor Monitor: VT07-B22L, VT07-B26L-W Software: ZKBio CVAccess, BioTalk Pro Mobile App: ZKBio Zlink, ZKBio Zexus |
| Power Supply | DC 12V 3A (Optional) |
| Operating Temperature | -5°c to 45°c |
| Operating Humidity | 10% to 90% RH (Non-condensing) |
| Dimensions | 183 mm * 88 mm * 20.5 mm (L*W*H) |
| Gross Weight | 0.503 kg |
| Net Weight | 0.453 Kg |
| Supported Software | On-Premise Software: ZKBio CVAccess (AC PUSH) & ZKBio Time (TA PUSH) Cloud-based Software: ZKBio Zlink (Supports Web Portal & Mobile App) |
| Installation | Wall-mount (Compatible with Asian Gang-box / Single Gang-Box) |
| Ingress Protection Rating | IP65 (waterproof and dustproof) |
| Certifications | ISO14001, ISO9001, CE, FCC, RoHS |
