Model |
DG04-A2F15 |
DG04-A2F21 |
DG04-A2P21 |
DG04-A2F26 |
DG04-A2F42 |
DG04-A2F58 |
Dimensions External |
37.11*48.43*9.1 | 72.31*34.31*9.1 | 72.31*34.31*9.1 | 82.93*41.41*9.1 | 98.4*89*10.7 | 98.4*89*10.7 |
Active Screen Area |
27.6*27.6 | 48.6*23.7 | 48.6*23.7 | 60.1*30.7 | 84.8*63.6 | 118.8*88.2 |
Screen Size |
2.13 inches | 2.13 inches | 2.13 inches | 2.66 inches | 4.2 inches | 5.8inches |
Resolution |
200*200 | 250*128 | 212*104 | 296*152 | 400*300 | 648*480 |
Pixel Density |
188 | 131 | 111 | 125 | 120 | 138 |
Display Colour |
BWR/BWY/BW | BWR/BWY/BW | BW | BWR/BWY/BW | BWR/BWY/BW | BWR/BWY/BW |
Battery Type |
CR2450 * 1 | CR2450 * 1 | Specific low temperature battery | CR2450 * 2 | CR2450 * 4 | CR2450 * 4 |
Battery Lifetime |
3 Years (5 updates/day) |
3 Years (5 updates/day) |
3 Years (5 updates/day) |
5 Years (5 updates/day) |
5 Years (5 updates/day) |
5 Years (5 updates/day) |
Display Technology |
EPD | EPD | EPD | EPD | EPD | EPD |
Communication Protocol |
2.4G | 2.4G | 2.4G | 2.4G | 2.4G | 2.4G |
Viewing Angle |
Near 180° Viewing Angle | Near 180° Viewing Angle | Near 180° Viewing Angle | Near 180° Viewing Angle | Near 180° Viewing Angle | Near 180° Viewing Angle |
Operating Temperature |
0 °C - 50 °C | 0 °C - 50 °C | -25 °C - 25 °C | 0 °C - 50 °C | 0 °C - 50 °C | 0 °C - 50 °C |
Storage Temperature |
-20 °C -60 °C | -20 °C -60 °C | -20 °C -60 °C | -20 °C -60 °C | -20 °C -60 °C | -20 °C -60 °C |
Water Features
(IP Rating) |
IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 |
Fixing Ways |
Shelf Rail/Bracket/ Ice Plug etc. |
Shelf Rail/Bracket/ Ice Plug etc. |
Shelf Rail/Bracket etc. | Shelf Rail/Bracket/ Ice Plug etc. |
Shelf Rail/Bracket etc. | Shelf Rail/Bracket etc. |
Compliance |
BQB/FCC /CE/RoHS |
BQB/FCC /CE/RoHS |
BQB/FCC /CE/RoHS |
BQB/FCC /CE/RoHS |
BQB/FCC /CE/RoHS |
BQB/FCC /CE/RoHS |
